JA Solar 460W N-Type Double Glass Bifacial Low Carbon Module (Black Frame, MC4-EVO2 Connectors)

The JA Solar 460W N-Type Double Glass Bifacial Module is engineered for superior performance, durability, and traceability. Designed with the latest MBB n-type solar cell and half-cell configuration, this module ensures higher output power, improved efficiency, and long-term reliability. Ideal for residential, commercial, and industrial installations, it combines cutting-edge technology with robust design to deliver maximum energy yield even under low-light or high-temperature conditions.

Product Feature:

• High Power Output (460W): Exceptional energy generation performance suitable for a wide range of applications.
• Advanced N-Type Cell Technology: Increases efficiency and minimizes degradation over time, ensuring sustained power output.
• Durable Double Glass Design: Enhanced protection against environmental factors like moisture, dust, and temperature fluctuations.
• Bifacial Technology: Captures sunlight from both the front and rear surfaces for increased energy yield.
• Integrated Traceability System (LB Traceable): Ensures complete transparency and quality assurance through JA Solar’s advanced traceable module technology.
• Premium MC4-EVO2 Connectors: Equipped with Staubli MC4-EVO2 connectors for secure and efficient electrical performance.
• Warranty: 25-year product warranty and 30-year linear power output warranty.

Product Specification:

– Rated Power: 460W
– Module Efficiency: 23.0%
– Weight: 22 kg
– Dimensions: 1,762 mm (L) × 1,134 mm (W) × 30 mm (D)
– Pallet Size: Oversized
– Electrical Characteristics (STC)
– Maximum Power Voltage (VMPP): 33.17 V
– Maximum Power Current (IMPP): 13.87 A
– Open Circuit Voltage (Voc): 39.7 V
– Short Circuit Current (Isc): 14.64 A
– Temperature Coefficient (Pmax): -0.29% / °C

Mechanical & Design Features
– Cell Type: N-Type Monocrystalline, Half-Cell, Double Glass Bifacial
– Frame Colour: Black
– Connector Type: MC4-EVO2
– Connector Description: Staubli MC4-EVO2 connectors for secure and efficient electrical connections
– Clamp Position: Long and short sides for flexible mounting options

Certifications & Warranty
– Product Warranty: 25 years
– Linear Power Output Warranty: 30 years
